Advantech PCA-6773 Series - USB Connectors (CN9,CN25)

19 Chapter 2 Installation
2.15.6 Panel type selection (S1)
S1 is an 8 segment DIP switch for DSTN/TFT panel type and resolution
functions.
2.16 USB connectors (CN9,CN25)
The PCA-6773 board provides up to four USB (Universal Serial Bus)
ports. This gives complete Plug and Play, and hot attach/detach for up to
127 external devices. The USB interfaces comply with USB specification
Rev. 1.1, and are fuse protected.
The USB interface is accessed through the 5 x 2-pin flat-cable connector,
CN25 (USB1, 2),CN9(USB3, 4). You will need an adapter cable if you
Table 2.6: S1 Panel Type select
SW
1-1
SW
1-2
SW
1-3
SW
1-4 Panel Type & Resolution
ON ON ON ON TFT 640x480** 18bit (H. V. Freq)
ON ON ON OFF TFT 648x480 18bit (Synthetic)
ON ON OFF ON TFT 648x480** N/A
ON ON OFF OFF TFT 648x480** LVDS
ON OFF ON ON DSTN 648x480** 18bit
ON OFF ON OFF TFT 800x600** 18bit (H. V. Freq)
ON OFF OFF ON TFT 800x600 18bit (Synthetic)
ON OFF OFF OFF TFT 800x600** LVDS
OFF ON ON ON TFT 800x600** N/A
OFF ON ON OFF DSTN 800x600** 18bit
OFF ON OFF ON TFT 1024x768** 36bit (H. V. Freq)
OFF ON OFF OFF TFT 1024x768** 36bit (Synthetic)
OFF OFF ON ON TFT 1024x768** LVDS
OFF OFF ON OFF TFT 1024x768** N/A
OFF OFF OFF ON DSTN 1024x768** 18bit
OFF OFF OFF OFF DSTN 1024x768** 24bit
* Default setting
** will support in the future
