13 WISE-4610(P) User Manual
Chapter 2 Hardware Installation
2.5 Pole Mounting
For pole mounting, feed the pole-mounting ring through the hole in the middle of the
module. The pole-mounting ring must be unlocked with a screwdriver before inserting
it into the module. To mount the module on the pole, tightly lock the pole-mounting
ring.
Figure 2.9 Pole Mount Bracket Installation (Front View)
Figure 2.10 Pole Mount Bracket Installation (Rear View)
