4.2.6 Multiple Power Sources
WISE-4610 is compatible with three sources of power: batteries, DC power, and solar
panels. The power source detection, power fail (remove cable and solar power), low-
battery, and suspend LEDs will vary depending on the power source:
 Low-Battery Indicator - When the remaining battery capacity is 20% or less, the
low-battery LED will blink slowly.
 Low-Battery Suspend - When the remaining battery capacity is 10% or less,
module operations will be suspended.
Table 4.12:
Power Combination Module Features
DC
Power
Solar
Panel
Battery
Power source
detection
Power fail
(remove cable
and solar panel)
Low battery
Switch Error LED Suspend
Y
Y
Y
ON
Cable,
battery
No PF signal,
system running
Slow blink if
≤20%
No
OFF PF
N Cable PF
N
Y
ON
Cable, bat-
tery
No PF signal,
system running
Slow blink if
≤ 20%
No
OFF PF
N Cable PF
N
Y
Y
ON
Solar panel,
battery
No PF signal,
system running
Slow blink if
≤20%
No
OFF PF
N Solar panel PF
N
Y
ON Battery
No PF signal
(battery cannot
be removed)
Slow blink if
≤20%
Suspend if
≤ 10%
OFF
Module is not working
N
Table 4.13:
Power Cable (DC/Panel)
Battery Power
Action Keep counter values
Switch
Y
N Remove power cable Yes
Y Y
ON
Remove power cable
Based on battery level
OFF No
N
Y
ON Switch ON→OFF No
