WISE-4610(P) User Manual 16
3.1 LoRa (Model: WISE-4610P)
 Frequency Band: EU 863-870 (MHz)/US 902-928 (MHz)/AU 915-928 (MHz)/
AS 919-924 (MHz)/JP 920-928 (MHz)
 Spreading Factor: 7~12
 Transmit Power: Up to +18 dBm
 Receiver Sensitivity: Up to -136 dBm at SF = 12/125 KHz
 Data Rate:
– 50 kbps at FSK mode EU868
– 21.9 kbps at SF7 mode US915
– 5.47 kbps at SF7 mode JP923/AS923
 Topology: Star
3.2 GPS
 GNSS Systems: GPS, GLONASS, Galileo, BeiDou, QZSS, and SBAS signals
 Maximum Update Rate:
– Single GNSS: Up to 18 Hz
– Concurrent GNSS: Up to 10 Hz
 Positioning Accuracy:
– 2.5 m CEP (50% confidence)
– With SBAS: 2.0 m CEP (50% confidence)
 Acquisition:
– Cold Starts: 57 s
– Aided Starts: 7 s
3.3 General
 RTC Accuracy: ±2 s/day
 Enclosure: PC + PBT
 Mount Options: DIN rail, wall, and pole
 Dimensions (W x H x D): 82 x 122 x 49 mm/3.22 x 4.8 x 1.92 in (without
antenna)
 Operating Temperature:
– With rechargeable battery: 0 ~ 60 °C (32 ~ 140 °F)
– Without battery: -25 ~ 70 °C (-13 ~ 158 °F)
 Storage Temperature:
– With rechargeable battery: -20 ~ 60 °C (-4 ~ 140 °F)
– Without battery: -40 ~ 85 °C (-40 ~ 185 °F)
 Operating Humidity: 25 ~ 95% RH (non-condensing)
 Storage Humidity: 0 ~ 95% RH (non-condensing)
Note! The storage and operation of WISE-4610 modules MUST be in environ-
ments that meet the temperature specifications.
