Chapter 4 Software Functions
*Note 1
4.2.4 Battery Charging
The battery IC serves as a gauge for estimating the remaining battery capacity.
Table 4.7:
Error LED
Signal LEDs
Description
1st
(poor)
2nd
(Okay)
3rd
(Good)
4th
(Full)
Error
Fast Blink
OFF OFF OFF Fast Blink RF related Error
OFF OFF Fast Blink OFF I/O Error
OFF OFF OFF OFF FW error
Slow Blink OFF OFF OFF OFF Battery related Error
OFF OFF OFF OFF OFF No error
Table 4.8:
Items Values Description
Remaining Battery
Capacity
0 ~ 100%
An unsigned integer value of the predicted remaining
battery capacity expressed as a percentage of full-charge
capacity, with a range of 0 to 100%.
Cycle Count 0 ~ 65535
An unsigned integer value of the number of cycles the
battery has undergone
Temperature °C
An unsigned integer value of the battery temperature in units
of 0.01 °C.
* Temperature: 0x06/0x07 command used. It should be the
external thermistor temperature.
