35 WISE-4610(P) User Manual
Chapter 4 Software Functions
Battery Temperature and Charging
4.2.5 Membrane Button
Refer to Section 4.2.3 “LED Indicator Behaviors” for detailed information regarding
the membrane button functionality:
In the “DC Power Only” or “DC Power and Battery” modes, when WISE-4610 is
powered via the power cable:
1. The LED indicators are turned OFF as the default setting.
2. To check the battery capacity, press the membrane button to light up the battery
capacity indicator.
3. Press the membrane button again to turn OFF the LED indicators and revert to
State 1.
4. If the power cable is removed and WISE-4610 is powered by the battery, the
module will enter “Battery Power Only” mode.
In “Battery Power Only” mode:
1. The LED indicators are turned OFF as the default setting. The Status/Error/Rx/
Tx/COM LEDs will light up for 15 seconds only.
2. In State 1, all LED indicators will automatically turn OFF after 15 seconds to
save power.
3. In State 1, when the membrane button is pressed, all LED indicators, including
the four battery capacity indicators, will light up. The indicators will automatically
turn OFF after 15 seconds.
4. In State 3, press the membrane button again to turn OFF the LED indicators.
5. When all LED indicators are not illuminated, press the membrane button again
to revert to State 1.
6. When connected to the power supply cable, WISE-4610 will enter either the
“DC Power Only” or “DC Power and Battery” modes.
Table 4.11: Battery Temperature and Charging
Battery Temp. T (°C) Battery Level % Charging
1 T < 0 - Stop charging
2
0
≤T≤45
- Allow charging
3
45 < T
≤ 60
> 10% Stop charging
≤ 10%
Charge to 20% only
4 T > 60 - Stop charging
