WISE-4610(P) User Manual 34
Battery Events
Table 4.9:
Operating
Status
Flags
Flag Bit Definitions
Bit Content
15 OTC
14 OTD
13 BATHI
12 BATLOW
11 CHG_INH
10 RSVD
9 FC
8 CHG
7 OCVTAKEN
6 ISD
5 TDD
4 HW1
3 HW0
2 SOC1
1 SOCF
0 DSG
OTC = Over Temperature in Charge condition detected. True when set.
OTD = Over Temperature in Discharge condition detected. True when set.
BATHI = Battery High bit, indicating a high battery voltage condition.
BATLOW = Battery Low bit, indicating a low battery voltage condition.
CHG_INH = Charge Inhibit indicates the temperature is outside the range
[Charge Inhibit Temp Low, Charge Inhibit Temp High]. True when set.
FC = Fully charged condition reached (RMFCC = 1; Set. FC_Set% = -1%
when RMFCC = 0). True when set.
CHG = (Fast) charging allowed. True when set.
OCVTAKEN = Cleared when switched to Relax mode, and set to 1 when OCV
measurement is performed in Relax mode.
ISD = Internal Short is detected. True when set.
TDD = Tab Disconnect is detected. True when set.
HW [1:0] Device Identification. Default is 01.
SOC1 = State-of-Charge Threshold 1 (SOC1 Set) reached. True when set.
SOCF = State-of-Charge Threshold Final (SOCF Set%) reached. True when
set.
DSG = Discharging detected. True when set.
Table 4.10: Battery Events
Events Condition
Error LED
(Slow Blink)
Low voltage Remaining battery capacity <= 20% V
Over Temperature in Charge con-
dition detected
Battery temperature < 0 °C or > 60 °C
Over Temperature in Discharge
condition detected
OTD flag of Operating Status set
Internal Short detected ISD flag of Operating Status set V
Fully charged condition reached FC flag of Operating Status set
