53 WISE-4610(P) User Manual
Appendix A Modbus Table with WISE-4610
Table A.7: *4 Power source
Bit Order Description
0 Line power
1 Battery
2 Solar panel
3~15 Reserved
Table A.8: Modbus Type Code
0 0x0103 -150mv~150mv
1 0x0104 -500mv~500mv
2 0x0140 -1v~1v
3 0x0142 -5v~5v
4 0x0143 -10v~10v
5 0x0105 0~150mv
6 0x0106 0~500mv
7 0x0145 0~1v
8 0x0147 0~5v
9 0x0148 0~10v
10 0x0180 4mA~20mA
11 0x0181 -20mA~20mA
12 0x0182 0~20mA
13, 14 (Reserved)
15 0x03A9 PT100(385) -200~ +600°C
16 0x03C9 PT100(392) -200~ +600°C
17 0x03E2 PT1000 -40~ +160°C
