d) Distribution system
1 - inlet valve, 3-fold
2 - hose for main wash
3 - hose for bleach
4 - hose for prewash
5 - product box, 4-fold
6 - water distributor
7 - cover for water distributor
1 - inlet valve, 2-fold
2 - hose for main wash
3 - product box, 3-fold
4 - hose for prewash
5 - water distributor
6 - cover for water distributor
*) Attention!
Flushing in via the soft rinse detergent
drawer is made possible through
simultaneous filling with hoses 2 and 4.
