- 23 -
TSE-N 01.03 A.B. 599 50 75 69 EN
Accessibility of Components
Besides the main electronic the accessibility of components is to be taken from Service Manual
5995070 53.
Replace the main circuit board
1. Remove the right side panel.
2. Detach the support panel and the support plate.
3. Remove the two screws of the electronic fixation.
4. Unlock the support of the lines at the rear panel.
5. Unlock the analog pressure switch.
6. Detach the lines to the board and remove the board.
