- 12 -
TSE-N 01.03 A.B. 599 50 75 69 EN
Water Inlet Valve
1 - inlet valve, 3-fold
2 - hose for main wash
3 - hose for bleach
4 - hose for pre-wash
5 - 4-chamber detergent box
6 - water distributor
7 - water distributor cover
1 - inlet valve, 2-fold
2 - hose for main wash
3 - 3-chamber detergent box
4 - hose for pre-wash
5 - water distributor
6 - water distributor cover
*) Attention!
The simultaneous filling through hoses 2 and 4 provides the fill-in through the softener chamber.
