AEG Electrolux EMW2000 - Accessing Electronic Module and Water Distributor; Functional Support Access; Water Distributor Cover and Distributor

- 18 -
HV844-N 12.01 R.B. 599 51 30 44 EN
7) Functional support
The removal of the functional support permits the access to:
- Connections of components;
- on/off key;
- water distributor;
- key;
- signal lamp;
- electronic;
- pressure switch;
- program selector
a) Disassembling
1 - Remove the control panel.
2 - Unscrew the 3 fixation screws
from the functional support.
3 - Remove the functional support.
b) Assembling
Put on the functional support and fix it with 3 screws.
Warning: Take care to the wiring when assembling.
8) Water distributor cover and water distributor
1 - Remove the functional support.
2 - Remove one screw.
3 - Remove the water distributor cover.
Warning: Take care that the cover of the water
distributor is sealed with silicone when assembling.
1 - Remove the water distributor.
