- 20 -
HV844-N 12.01 R.B. 599 51 30 44 EN
10) Inlet valve
a) Disassembling
1 - Remove the left side panel.
2 - Remove the valve cover.
3 - Pull off the distribution hoses (2 or 3 following model).
4 - Unscrew the inlet hose.
5 - Unlock the inlet valve with the connecting piece from the
base.
6 - Unscrew the connecting piece from the inlet valve.
11) Drain pump
1 - Remove the left side panel.
2 - Tilt the appliance to the back.
3 - Unlock the clips for pump and connection part (following appliance).
4 - Pull out the pump from the rear.
If (when you disassemble the drain pump or the connection part of drain pump/circulation
pump), one of its fixation clips has been broken, use the screws with reference no.
6020190-01/0.
12) Circulation pump
Proceed as described above.
Warning: Take care after reassembling to the correct position of the “direct spray” hose.
13) Motor
a) Disassembling
1 - Remove the left and right side panel.
2 - Remove the drive belt.
3 - Pull off the earth connection and the motor plug.
4 - Remove the 3 fixation screws.
5 - Take out the motor.
