Cleaning and care54
Cleaning the door glass panels
Clean the door glass panels thoroughly with a solution of water and washing up
liquid. Then dry them carefully.
Putting the door glass panels back.
1. From above insert the door glass panels
one after the other into the door profile at
the bottom edge of the door at an angle
and lower them.
3 The two smaller panels first, then the larger
panel.
2. Take hold of the door trim (B) at each side,
position it on the inside edge of the door
and plug the door trim (B) into the upper
edge of the door.
3 On the open side of the door trim (B) there
is a guide bar (C). This must be pushed be
tween the outer door panel and the guide
corner (D).
The clip seal (E) must be snapped in.
