53Cleaning and care
Oven door glass
The oven door is fitted with four panels of glass mounted one behind the other.
The inner panels can be removed for cleaning.
1 Important Rough handling, especially around the edges of the front panel, can
cause the glass to break.
Removing door glass panels
1. Open the oven door as far as it will go.
2. Undo the clamping levers (A) on both
door hinges fully.
3. Close the oven door as far as the first posi
tion (approx. 45°).
4. Take hold of the door trim (B) on the upper
edge of the door at both sides and press in
wards to release the clip seal. Then remove
the door trim by pulling it upwards.
5. Take hold of the door glass panels on their
upper edge one after the other and take
them out of the guide by pulling them up
wards.
