AEG LR8E70480 - Page 19

1
2
8. Pull up the appliance in vertical position.
9. Remove the power supply cable and the drain hose from the
hose holders.
It is possible to see water flowing from the drain hose. This is
due to the testing with water of the appliance in factory.
10.Remove the three bolts by using the spanner supplied with the
appliance.
19/96
INSTALLATION
