AEG THYRO-A User Manual

22
P Output power (only for ...H RLP1)
If the load resistance changes, e.g. due to temperature, ageing or
load interrupt, the variables influencing the load change.
Tab. 1 Effects of a change in the load resistance
Control mode Load resistance becomes smaller Load resistance becomes greater
P U
Load
I
Load
P U
Load
I
Load
U greater = greater smaller = smaller
U
2
greater = greater smaller = smaller
I*
1
smaller smaller = greater greater =
I
2
*
1
smaller smaller = greater greater =
P *
2
= smaller greater = greater smaller
( *
1
for ...H RL1 and ...H RLP1, *
2
only for ...H RLP1)
