Page #50 background imageLoading...
Page #50 background image
50
Tab. 6a Analog output (scale) Thyro-A 1A, 2A
Setting
1A (H, HRL1, HRLP1) at
2A (HRLP1) at
(default = 0-20mA,
U-, I-, P display -
P display
corresponds to type value
2A (H, HRL1, HRLP1) at
Potentiometer R204
(current/voltage/power)
U-, I-display
SCALE OUTPUT
Potentiometer R204
SCALE OUTPUT
Potentiometer turns 4 turns * (type value power 4.62 turns * (P
type power controller
/
(from left stop)
controller / scale end value) scale end value)
Setting aid, analog output 4mA * (type value power 4.62mA * (P
type power controller
/
in mA
controller / scale end value) scale end value)
(Switch S1.10 = „OFF“)
Setting aid, analog output 2V * (type value power 2.13V * (P
type power controller
/
in mA
controller / scale end value) scale end value)
(Switch S1.10 = „ON“)
Tab. 6b Analog output (scale) Thyro-A 3 A
Setting 3A (H, HRL1) at 3A (HRLP1) at
(default = 0-20mA, U-, I display P display*
1
corresponds to type value/
Potentiometer R204 Potentiometer R204
(current/voltage/power)
SCALE OUTPUT SCALE OUTPUT
Potentiometer turns
3.6 turns * (type value power 6.24 turns * (P
type power controller
/
(from left stop)
controller/scale end value) scale end value)
Setting aid, analog output
4mA * (type value power 6.93mA * (P
type power controller
/
in mA
controller/scale end value) scale end value)
(Switch S1.10 = „OFF“)
Setting aid, analog ouput
2V * (type value power 3.46V * (P
type power controller
/
in volts
controller/scale end value) scale end value)
(Switch S1.10 = „ON“)
Analog output: X2.9 (+); X2.5 (ground) *1 only with ...H RLP1
4.3.6
Adapting analog output (scale) (only for ...H RL1 and ...H RLP1)
The scale of the analog output is adapted with potentiometer R204
SCALE OUTPUT, if, for example, the scale of the display does not cor-
respond to the nominal data (see page 41, Analog output).
Example adaptation at the analog output
Thyro-A 3A 400-30 H RLP1 (U
type
= 400V, I
type
= 30A, P
type
= 20.7kW)
Measuring instrument for 4-20 mA with scale 20 kW
Setting aid
Setting R204: 6.24 * (20,7kW/20kW) 6.5 turns
(from left stop)
Setting aid in mA: 6.93mA * (20,7kW/20kW) 7.17mA
Setting aid in V: 3.46V * (20,7kW/20kW) 3.58V
