Terminal Description Grid
dimension
X3* .3 N/C contact, closed when there is a fault
.2 N/O contact, open when there is a fault 5.08
(closed circuit principle)
.1 Root, common connection
X22 .7 Control ground
.6 Connection to slave
.5 Connection to slave
.4 Control ground 3.5
.3 RxD / Connection to bus module
.2 TxD / Connection to bus module
.1 Bus module detection / setpoint selection
X2 .10 Ground potential, maybe shield control conductor
.9 Analog output 0-10V or 0(4)-20mA
.8 + 5V output e.g. for a setpoint potentiometer
(5k
R
Poti
10k)
.7 Sync. In (SYT-9)
.6 Sync. Out 3.5
.5 Control ground
.4 Analog setpoint input max. 10V, max. 20mA
.3 Control ground
.2 Pulse inhibition (PULSE INHIBIT)
.1 Control ground
X11* .2 24V extra electronics supply
AC or - DC 3.5
.1 24V extra electronics supply
AC or + DC
X1 .2 Works connection (do not alter!)
.1
* only for ...H RL1 and ...H RLP1
5.1 Connecting terminals (Overview)
Tab. 11 Connecting terminals (Overview)
