71
EN
7. Connection diagrams
Fig. 4 Connection diagram Thyro-A 1A… H1
5..10 K
Mains supply
L1 L2 (N)
+5V
+
fan only for
HF - Types
230V, 50/60Hz
X7 2
3
Configuration S1.
X22 1 2 3 4 5-7
Connection for bus
module option
Status
PE
Shield / Ground
Pulse inhibit
Setpoint
Sync. Out
Sync. In SYT-9
Pot. supply
X2 1 2 3 4 5 6 7 8 9 10
R 201
Trafo adaption
or
end value controller
(S1.5)
H 101
H 100
Pulse Inhibit
Power On
H 350 Diagnostic (Intern)
Parameter
F1
Semi-
conductor-
Fuse
F
2A / slow acting
(only required in case
of phase connection
e.g. L2)
R
Load
X1 1 2
Thyro-A
1A ... H(F) 1
Operating Mode
Set Point Input
Set Point Input
Set Point Live Zero
Function R201/ Thyro-Tool
Control Mode / Thyro-Tool
Control Mode / Thyro-Tool
Operating Mode
10
9
8
7
6
5
4
3
2
1
U1 U2
for UL-applications refer to Technical
Data, Connector Data (power circuit)
⍀
Use shielded
control lines!
