47
EN
setpoint, the SST becomes smaller and the ramp is always crossed
once fully.
NOTE
Setting AN1, SST and T
0
independently
When a bus module or Thyro-Tool Family are used,
parameters AN1, SST and T
0
can be set independently of
one another.
• Setting potentiometer TRAFO ADAPTION R201 to left stop.
> At <30°el the device automatically switches to a faster Takt operati-
on with T0 = 5 periods without SST. Then terminal X2.7 can be used
as control input for switch operation.
When using the synchronization options, via R201 must
be set parameter AN1 >30° el (T
0
= 1000ms).
Analog output (setting aid)
10.0mA / 5V 100°el
6.0mA / 3,0V 60°el Thyro-A 1A (default)
9.0mA / 4,5V 90°el Thyro-A 2 & 3A (default)
3.0mA / 1,5V 30°el
2.5mA / 1,25V 0°el
4.3.3 Setting maximum load value with control end U, U
2
and P
control
For ...H RL1 and ...H RLP1
With potentiometer R202 SCALE SETPOINT, the maximum voltage
(for U, U2 control) or the maximum power (for P control) is set on the
load, depending on the control mode *
1
. If no P control is set, the po-
tentiometer works as voltage limitation. The end value of the control
characteristic is adapted accordingly (see following table).
Analog output: X2.9 (+); X2.5 (ground)
*
1
only for ...H RLP
• Set maximum load value (of U or P) at control end on potentiometer
R202 SCALE SETPOINT.
