72
5..10 K
3
Mains supply
Rotating field: clockwise
L1 L2 L3
Load
Master
Slave
X22 5
System X22
6 7 X22 5
System X22
6 7
*wired ex works
+5V
+
3
Thyro-A
2A ... H(F) 1
fan only for
HF - Types
230V, 50/60Hz
X7 2
3
X1 1 2
Master
Slave
X1 1 2 5-7X22
U1 U2 W1 W2
Configuration S1.
X22 1 2 3 4 5-7
Connection for bus
module option
Status
PE
Shield / Ground
Pulse inhibit
Setpoint
Sync. Out
Sync. In SYT-9
Pot. supply
X2 1 2 3 4 5 6 7 8 9 10
R 201
Trafo adaption
or
end value controller
(S1.5)
Operating Mode
Set Point Input
Set Point Input
Set Point Live Zero
Function R201/ Thyro-Tool
Control Mode / Thyro-Tool
Control Mode / Thyro-Tool
Operating Mode
10
9
8
7
6
5
4
3
2
1
H 101
H 100
Pulse Inhibit
Power On
H 350 Diagnostic (Intern)
Parameter
F1
Semi-
conductor-
Fuse
for UL-applications refer to Technical
Data, Connector Data (power circuit)
Load
F
2A / slow acting
F1
Semi-
conductor-
Fuse
H 100 Power On
H 350 Diagnostic (Intern)
⍀
Use shielded
control lines!
Fig. 5 Connection diagram Thyro-A 2A… H1
