3
EN
3.9.2 Load monitoring (only for ...H RL1 and ...H RLP1) 33
3.9.3 Device temperature monitoring 33
3.9.4 Fan monitoring (for ...F...) 33
3.10 Extended functions
(with bus module / THYRO-TOOL FAMILY) 33
3.10.1 Extended operating modes / circuit types 34
3.10.2 Averaging for the analog output 35
3.10.3 Control limits 35
3.10.4 Controller parameters 35
3.10.5 Mains load optimization 35
4. Settings and operation 36
4.1 Device overview 37
4.2 DIP switches S1 39
4.2.1 Operating mode and load types 41
4.2.2 Control mode / Analog output 41
4.2.3 Live zero and setpoint input range 43
4.2.4 Analog output (only for ...H RL1 and ...H RLP1) 43
4.3 Potentiometer 44
4.3.1 Setting the transformer load (AN1, SST, T
0
) 45
4.3.2 Setting ohmic load 46
4.3.3 Setting maximum load value with control end U, U
2
and P control 47
4.3.4 Setting maximum load current
(only for ...H RL1 and ...H RLP1) 48
4.3.5 Setting example for maximum load value at control
end / maximum load current 49
4.3.6 Adapting analog output (scale)
(only for ...H RL1 and ...H RLP1) 50
4.3.7 Setting load monitoring (undercurrent monitoring)
(only for ...H RL1 and ...H RLP1) 51
5. Installation 58
5.1 Connecting terminals (Overview) 60
5.2 Connecting power supply 62
5.3 Connecting additional electronics supply
(only for ...H RL1 and ...H RLP1) 62
5.4 Connecting pulse inhibition 63
