40
* only for ...H RL1 and ...H RLP1
* only for ...H RL1 and ...H RLP1
* only for ...H RL1 and ...H RLP1
Switch Function Default setting
S1.10 Analog output 10V / 20mA* ON 0-10V
S1.9 Live Zero analog output* OFF
S1.8 Setpoint input ON 0-20mA
S1.7 ON
S1.6 Live zero setpoint OFF 0mA
S1.5 Control mode / Thyro-Tool mode OFF U
2
S1.4 OFF
S1.3 OFF
S1.2 Operating mode OFF TAKT
S1.1 ON
DIP switches S1 Thyro-A 1A… H1/HRL1 and Thyro-A 2A… H1/ HRL1
Switch Function Default setting
S1.10 Analog output 10V / 20mA* ON 0-10V
S1.9 Live zero analog output* OFF
S1.8 Setpoint input ON 0-20mA
S1.7 ON
S1.6 Live zero setpoint OFF 0mA
S1.5 Control mode/ Thyro-Tool mode ON P
S1.4 OFF
S1.3 ON
S1.2 Operating mode OFF Takt
S1.1 ON
DIP switches S1 Thyro-A 1A… HRLP1 and Thyro-A 2A… HRLP1
Switch Function Default setting
S1.10 Analog output 10V / 20mA* ON 0-10V
S1.9 Live zero analog output* OFF
S1.8 Setpoint input ON 0-20mA
S1.7 ON
S1.6 Live Zero setpoint OFF 0mA
S1.5 Control mode / Thyro-Tool mode OFF U
2
S1.4 OFF
S1.3 OFF
S1.2 Operating mode ON VAR
S1.1 OFF
DIP switches S1 Thyro-A 3A
