66
• Switch off mains supply and secure against accidentally being swit-
ched back on.
• Remove connector (connection to slave) of terminal X22.
• Plug PC interface RS232 with the „Thyro-A“ side into terminal X22.
• Plug in connector (connection to slave) at PC interface RS232.
• Connect serial interface (COM) to PC using RS232 data cable (Or-
der no.: 0048764; not crossed; connections 2,3,5,4 and 7 used).
> The device can be operated with the THYRO-TOOL FAMILY. Mea-
sured values and parameters are displayed in the software. Exten-
ded functions can be set (see page 33, Extended functions).
> Only for operation of the device in Thyro-Tool mode (S1.3 to S1.5
to ON): All parameters can be set with the THYRO-TOOL FAMILY.
NOTE
Switching over defined setpoint on the PC interface
A switch can be connected to terminals X1.2 and X1.3
of the PC interface RS232 to switch over the defined
setpoint.
- For contact X1.2 with X1.3: Digital defining of setpoint with THYRO-
TOOL FAMILY and temporary Thyro-Tool mode.
- For no contact X1.2 with X1.3: Analog defining of setpoint with ter-
minal X2.4 (see page 19, Setpoint processing)
