Ground Resistance Tester Model 6471
51
7.2 Recalling Measurements from Memory
To recall saved measurements, perform the following:
• Select a measurement function, then press the and MR buttons.
• Use the ► and ▲▼ buttons to choose the OBJ and TEST numbers.
• Press the DISPLAY button to display the time (tiME) and date (dAtE).
• Press DISPLAY again to display the measurement and its parameters.
• Press the MR button again to exit the recall mode.
The SET-UP function lets you read all memory addresses one after the other
independently of which measurement function is chosen.
Any measurement stored in the tester can be retrieved individually using Data-
View
®
software (see § 8).
7.3 Erasing Measurements from Memory
There are two ways to erase measurements - complete and selective.
7.3.1 Erasing All Measurements
• Set the switch to SET-UP.
• Push once on the MEM button to display the number of free and available
records.
• Push a second time on the MEM button.
• The display will show “dEL ALL”. Change the blinking NO to YES with the ▲
button, then perform a long press (>2s) on the MEM button.
WARNING: This will delete ALL saved records.
• To exit without erasing, perform a short press on the MEM button.
7.3.2 Erasing Selective Measurements
• Set the switch to SET-UP.
• Press the button.
• Press the MR button. The Object and Test numbers of the last stored test ap-
pear, with the Object number blinking.
