GF-115-C

Modulex E8 Controller and BCM

Operations and Maintenance Manual

OMM-0084_0D

10.2 Fault Codes and Descriptions

Fault codes are displayed in the E8 Controller display. Use Table 10-1 below to determine the

actual fault code. There are codes for three different devices as follows:

• E8 Controller: These are divided into four basic categories: PCB Element Faults,

System Manager Faults, Communication Faults, and Internal Faults. These fault codes

are shown in Table 10-2.

• BCM (Boiler Control Module): These fault codes are shown in Table 10-3.

• BMM (Burner Management Module): These fault codes are shown in Table 10-4.

In order to derive the correct error code from that displayed in the E8 Controller display, use

Table 10-1 below to determine the working error code. To use the table, identify the displayed

number from the first column, identify the affected module from the second column, apply the

formula from the third column, and identify the Error Table to reference from the fourth column.

Table 10-1: Determining the “Error Code” Reading from the E8 Controller Display

Observed Code

Observed

Code

Code to Look Up in Table

Code = 0

N/A

No Fault

Code between 1 and 255 BMM #0 Fault Look up code 10-4

Code between 256 and 511 BMM #1 Fault Subtract 256 from reading 10-4

Code between 512 and 767 BMM #2 Fault Subtract 512 from reading 10-4

Code between 768 and 1023 BMM #3 Fault Subtract 768 from reading 10-4

Code between 1024 and 1279 BMM #4 Fault Subtract 1024 from reading 10-4

Code between

1280

and

1535

BMM #5 Fault Subtract

1280

from reading 10-4

Code between

1536

and

1791

BMM #6 Fault Subtract

1536

from reading 10-4

Code between 1792 and 2047 BMM #7 Fault Subtract 1792 from reading 10-4

Code between 2048 and 65279 N/A Invalid Codes -

Code above 65280 BCM Fault Subtract 65280 from reading 10-3

Example:

Based on the above, a code reading of “261” means the fault occurred on

BMM #1. The fault code is (261 – 256 = ) 5. An Error Code of 5 from the

BMM Fault Codes table means “Flame Loss During Run”.
