Modulex E8 Controller and BCM
Operations and Maintenance Manual
OMM-0084_0D
RANGE
SOLAR M/F Sub-Menu
MF (1-4)
FUNCTION
Not Applicable
MF (1-4)
SET TEMP
Not Applicable
MF (1-4)
HYST (1-4)
Not Applicable
F15 FUNCTION
F15 Function
00 = Room Sensor for Heating Circuit 2
01 = 0 – 10V iInput
02 = Light sensor
00 -02 00
RETURN
Press Program Key to exit SOLAR M/F
Sub-Menu.
4.4.1 Available V-Curve Preset Voltage Curves for 0 – 10 Volt Input
The following listing (Table 4-4) shows the available preset V-Curve settings for operation in
the 0 to 10 Volt Mode:
Table 4-4: V-Curve Preset Voltage Curves for 0 – 10 Volt Input
CURVE NO. U1 U2 T1 T2 UO
0 2.0 V 10.0 V 32°F 194°F 2.0 V
1 2.5 V 0.3 V 100°F 176°F 5.0 V
2 2.5 V 0.3 V 100°F 167°F 5.0 V
3
2.5 V
0.3 V
100°F
113°F
5.0 V
4 4.0 V 0.1 V 68°F 185°F 5.0 V
5
4.0 V
0.1 V
68°F
167°F
5.0 V
6 4.0 V 0.1 V 68°F 131°F 5.0 V
7
4.0 V
0.1 V
68°F
189°F
5.0 V
8 4.0 V 0.1 V 68°F 189°F 5.0 V
9
4.0 V
0.1 V
68°F
163°F
5.0 V
10 4.0 V 0.1 V 68°F 127°F 5.0 V
11
4.0 V
0.1 V
68°F
194°F
5.0 V
4.5 EXPERT HS Menu (Not Used)
(Not applicable to Modulex boilers)
