06/05/13 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 • Ph: 800-526- 0288 Page 96 of 112
GF-115-C
Modulex E8 Controller and BCM
Operations and Maintenance Manual
OMM-0084_0D
Table 9-4: BCM Standard Holding Register Address Mapping
Modbus Data
Address
Menu Item Units and Range Default/(Comments)
CONTROL REGISTERS
1
AERCO BMS
II/ACS Requested
Modulation Level
% (0 to 100)
(Read/Write)
A value other than 0
requests Run mode and
supersedes the value
set for Max Modulation
Level (address 0x03F9)
1017
Maximum
Modulation Level
% (0 to 100)
(Value x 2)
(Read/Write)
100° (50%)
1004 Requested Setpoint
32°F – 212°F (0°C – 100°C)
(Value x 10)
(Read/Write)
180°F
1001 System Command enum (0xAA)
(Read/Write)
0xAA: Restart Slave
identification procedure
1021
Heat Request
Command
enum
(0x01, 0x33, 0x44, 0x55,
0xBB, 0xCC, 0xEE)
0x01:
No action
0x33:
Space Heating
mode enabled
0x44:
Space Heating &
DHW modes
enabled
0x55:
DHW mode
enabled
0xBB:
Space Heating
requested & DHW
enabled
0xCC:
Check request
0xEE:
Space Heating
request
If enum is none of the above,
Standby is selected.
(Read/Write)
0x01
1022
Requested DHW
Setpoint
32°F – 212°F (0°C – 100°C)
(Value x 10)
(Read/Write)
1023 Pump Control
enum (0, 1, 2)
0 = No action
1 = Switch OFF
2 = Switch ON
(Read/Write)
1030
Error/Reset
enum (0x5A)
(Read/Write)
