MODULEX EXT 321, 481, 641, 802, 962, 1123 BOILERS
Installation, Operation & Maintenance Manual
Page 144 of 146 AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 OMM-0087_0F
07/13/15 Phone: 800-526-0288 GF-143
No. Part No. Description
27 95000931 Burner Chamber, End Section RH
28 95000932 Burner Chamber, Centre Section
29 95250612 Sealing Gasket-Flue box Outlet
30
95250618 Gasket - H/E-Flue Box, EXT 321
95250619 Gasket - H/E-Flue Box, EXT 481
95250620 Gasket - H/E-Flue Box, EXT 641
95250621 Gasket - H/E-Flue Box, EXT 802
95250622 Gasket - H/E-Flue Box, EXT 962
95250623 Gasket - H/E-Flue Box, EXT 1123
31 95250624 Igniter
32
95250847 Boiler Body Insulation, EXT 321
95250848 Boiler Body Insulation, EXT 481
95250849 Boiler Body Insulation, EXT 641
95250850 Boiler Body Insulation, EXT 802
32
95250851 Boiler Body Insulation, EXT 962
95250852 Boiler Body Insulation, EXT 1123
33 95251210 Graphite Electrode Gasket
34 95251274 Flame Detector
35 95251529 Return Manifold Gasket
36 95251587 Fan Blower Manifold Gasket
37 95251588 Fan NRG118 Gasket
38 95251592 Silicone Gasket
39 95251851 Sheath Bulbs
40 95251607 Gas Manifold Gasket
41 95251611 Flue Terminal D.200
42 95251841 Water Manifold Gasket
43 95261173 Burner Gasket
44 95263570 Signal Light
45 95261357 Boiler Drain Cock G 3/4"
46 95263452 Suction Hose
47 95261558 Main Switch
48 95263756 Air Pressure Switch 43/40 pa
49 95263767 Air Pressure Switch 280/245 pa
50 95262011 Screw + Washer + Nut kit (12 pcs)
51 95262129 Mixer DUNGS SW12 - RG130 - nozzle D.7
52 95262137 Thermostat 90-110°
53 95262207 E8 - System Manager
54 95263579 Ignition Transformer
55 95262208 External Sensor E8 - System Manager
56 95262209 Mixed Flow Sensor E8 - System Manager
57 95262211 Tank Sensor E8 - System Manager
