25
~
~
~
~~
KEY
1
Filter
2
3 bar safety valve
3
Draining tap
4
Circuator
5
Flow meter
6
NTC 10K water probe L=1.5 M
7
Condenser
8
Evaporator
9
Storage
10
Relief valve
11
Condenser side flow meter
12
Condenser side filter
TAB. 02 HEAT PUMP VERSIONS
