9
015 020 025 030
Cooling capacity kW 5,3 6,9 8,2 9,7
Total absorbed power kW 1,7 2,0 2,3 2,7
Evaporator water flow rate l/h 910 1.190 1.410 1.670
Condenser water flow rate l/h 1.190 1.500 1.780 2.100
Condenser pressure drop kPa 11,4 17,5 13,4 11,7
Condenser water consumption at 16 °C (1) l/h 320 400 470 560
Condenser water pressure drop at 16 °C kPa 1,0 1,5 1,2 1,6
ENERGY INDEXES
EER
W/W
3,12 3,45 3,57 3,59
ESEER
W/W
4,03 4,77 4,92 4,81
ELECTRICAL DATA
Power supply 230V
~
- 50 Hz
Absorbed current A 8,6 9,4 11,1 13,0
Maximum current A 13 15 18 24
Peak current A 48 61 76 100
COMPRESSORS (SCROLL)
Number per circuit/type n°/n° 1/Rotary 1/Scroll 1/Scroll 1/Scroll
EVAPORATOR (PLATES)
Number n° 1 1 1 1
Hydraulic connections ø gas M 1" 1" 1" 1"
CONDENSER (PLATES)
Number n° 1 1 1 1
Hydraulic connections ø gas M 1" 1" 1" 1"
STORAGE
Water storage l 23 23 23 23
PUMP
Absorbed power kW 0,095 0,165 0,18 0,2
Absorbed current A 0,42 0,8 0,8 0,8
Effective pressure to the plant kPa 54 63 61 59
SOUND DATA
Sound power level dB(A) 56,0 56,5 57,0 57,5
Sound pressure dB(A) 47,5 48,0 48,5 49,0
DIMENSIONS
Height mm 625 625 625 625
Width mm 404 404 404 404
Depth mm 504 504 504 504
EMPTY weight
kg 85 96 98 100
5.2 STANDARD VERSIONS TECHNICAL DATA (°)
In cooling mode
- Outlet water temperature 7 °C
- Water inlet temperature to condenser 30 °C
- ∆t 5°C
- Sound pressure measured in 85 m
3
semi-
reverberant test chamber with reverberation
time Tr = 0.5 sec.
NOTE
(1) The consumption of water at 16 °C refers
to a unit with pressure switch valve, which is
appropriately calibrated.
