42
SET POINT menu - PAGE 3
Visualisation on unit display Index Display/Parameter
A Page index: Identifies the menu and the corresponding page:
P = MAIN menu
S = SET-POINT menu
M = MAINTENANCE TECHNICIAN menu (Blocked)
C = MANUFACTURER’S menu (Blocked)
CK = CLOCK menu
The number associated to one of the previous codes, indicates
the page of the menu indicated.
B
DHW set-point: Indicates the work point reached at which the
unit stops. This value is inserted by the user and is included in
the range set by the installer at the time of installation.
C
Differential in DHW mode: Indicates the difference subtrac-
ted from the DHW set-point, in order to calculate the tempe-
rature at which the heat pump will switch-on to produce DHW,
this value is inserted by the user.
SET POINT menu - PAGE 2
Visualisation on unit display Index Display/Parameter
A Page index: Identifies the menu and the corresponding page:
P = MAIN menu
S = SET-POINT menu
M = MAINTENANCE TECHNICIAN menu (Blocked)
C = MANUFACTURER’S menu (Blocked)
CK = CLOCK menu
The number associated to one of the previous codes, indicates
the page of the menu indicated.
B
WINTER set-point: Indicates the work point reached at which
the unit stops. This value is inserted by the user and is inclu-
ded in the range set by the installer at the time of installation.
C
Differential in WINTER mode: Indicates the difference sub-
tracted from the WINTER set-point, in order to calculate the
temperature at which the heat pump will switch-on, this value
is inserted by the user
SET POINT menu - PAGE 1
Visualisation on unit display Index Display/Parameter
A Page index: Identifies the menu and the corresponding page:
P = MAIN menu
S = SET-POINT menu
M = MAINTENANCE TECHNICIAN menu (Blocked)
C = MANUFACTURER’S menu (Blocked)
CK = CLOCK menu
The number associated to one of the previous codes, indicates
the page of the menu indicated.
B
SUMMER set-point: Indicates the work point reached at
which the unit stops. This value is inserted by the user and is
included in the range set by the installer at the time of instal-
lation.
C
Differential in SUMMER mode: Indicates the difference sub-
tracted from the SUMMER set-point, in order to calculate the
temperature at which the heat pump will switch-on, this value
is inserted by the user
Parameters that can be modified by the user
Parameters that can be modified by the user
Parameters that can be modified by the user
Setpoint S2
Heating 23.0C
Diff. 03.0C
Setpoint S3
Sanitary 45.0C
Diff. 05.0C
Setpoint S1
Cooling 23.0C
Diff. 03.0C
A
B
C
A
B
C
A
B
C
