APPENDIX 2 - Key Operator training checklist 59
 Make sure the network card is 100/1000 Mbps.
 Make sure of a high speed hub or switch (if printing through hub / switch).
    Recommendedtohave2networkcardsintheCPU;onefortheofcenetwork
& the other for the Anapurna engine (cross over network cable).
 How to connect Wasatch with the :Anapurna M4F.
2. Anapurna M4F – Start Up Sequence.
a. Compressor & Drier (to get compressed dry air)
b. Exhaust (of the room)
c. Main Switch (Power), Circuit Breakers (if applicable), Power switch.
d. Emergency Buttons on Anapurna Engine.
  e. Power‘ON’(StartButton).
3. Anapurna Control Panel.
  a. ‘ONLine’&‘OFFLine’.
b. Local & Host.
c. Head Gap (Calib).
d. Parameters: Left, Top & Right Margins + Null Point (Y or N).
e. Nozzle Check (Prime).
  f. ‘Pause’function.
g. Cancelling a print.
4. Setting up the :Anapurna M4F & changing the parameters.
a. Calibrating the engine.
 Horizontal Alignment.
 Bi Direction Alignment.
 Step Size (Feed).
 Carriage Speed.
b. Print Head Test (Prime : Menu F1 on Control Panel).
c. Roll to roll print (optional).
 Media Loading.
 Vacuum Settings on the bed.
 Set Gap (Head Height Calibration in regard to the media thickness).
 Set Margins (Parameters).
 UV Lamps (Power settings: Full / Half and Mode settings: Normal / Both).
d. Rigid media printing.
 Media Set Bar.
 Vacuum Settings of the table.
 Set Gap (Head Height Calibration).
 Left & Top Margins.
 Input / output Support Tables.
 UV Lamps (Power settings: Full / Half and Mode settings: Normal / Both).
e. Negative Pressure Settings.
C. MAINTENANCE.
1. Print Head Purging / Cleaning (Function of 2 way valve).
  a. ‘Quick’Purgeif‘PrimeTest’(nozzletest)notgood.
  b. ‘Long’Purge.
  c. Head‘Bleeding’(dropthenegativepressuredownto-.010).
d. Head Cleaning using Cleaning Solution.
2. Heater Settings (How to change settings on the digital controls).
a. Sub Ink Tanks.
b. Head Base.
