1200 Series Quarternary Pump User Manual 107
Parts and Materials for Maintenance
8
Overview of Main Assemblies
Tab le 12 Repair Parts - Pump Housing and Main Assemblies (Front View)
Item Description Part Number
1 Pump head, see “Pump Head Assembly” on page 110 G1311-60004
2 Pump drive assembly
Exchange assembly — pump drive
G1311-60001
G1311-69001
3 Cable assembly — AIV to main board G1311-61601
4 Low-pressure pump main board (LPM)
Exchange assembly — LPM board
G1311-66520
G1311-69520
5Cable to MCGV G1311-61600
6Fan assembly 3160-1016
7Damping unit 79835-60005
8Leak pan—pump 5042-8590
9 Multi-gradient assembly (MCGV)
Exchange assembly — MCGV
G1311-67701
G1311-69701
10 Screw, M4, 40 mm lg — MCGV 0515-0906
-- Rubber holder — MCGV 1520-0401
11 MCGV cover G1311-44101
