1200 Series Quarternary Pump User Manual 115
Parts and Materials for Maintenance
8
Purge Valve Assembly
Purge Valve Assembly
Figure 29 Purge-Valve Assembly
Tab le 17 Purge-Valve Assembly
Item Description Part Number
Purge valve complete assembly G1311-60009
1 Valve body No part number
2 PTFE frit (pack of 5) 01018-22707
3 Gold seal 5001-3707
4 Cap (pack of 4) 5062-2485
)
(
'
&
