14 Increment to point “299” and set the end point to a value of “1”.
Use the left/right arrow keys to move between the point field (left) and
the floating-point value (right). As you modify the value, the end point is
output. When you press the Enter key, the line between the start point
and end point is calculated, output, and stored. If you exit without
pressing the Enter key, the start point and stop point are restored.
00299:+1.0000
15 Save the start and stop points and output the waveform.
COMPUTING
16 Save the waveform and turn off the menu.
The function generator beeps and displays a message to show that the
waveform is now stored in volatile memory. You are then exited from
the menu.
EXITING
17 Use Recall Menu to return to the
LINE EDIT command.
3: LINE EDIT
18 Move across to the
SAVE AS command on this level.
6: SAVE AS
Menu On/Off
Shift
Recall Menu
Shift
<
> > >
Enter
Chapter 3 Features and Functions
Arbitrary Waveforms
106
