Agilent Technologies 33120A - Output Configuration Commands

Output Configuration Commands
(see page 145 for more information)
[SOURce:]
FUNCtion:SHAPe {
SINusoid|SQUare|TRIangle|RAMP|NOISe|DC|USER}
FUNCtion:SHAPe?
[SOURce:]
FREQuency {<
frequency>|MINimum|MAXimum}
FREQuency? [MINimum|MAXimum]
[SOURce:]
PULSe:DCYCle {<
percent>|MINimum|MAXimum}
PULSe:DCYCle? [MINimum|MAXimum]
[SOURce:]
VOLTage {<
amplitude>|MINimum|MAXimum}
VOLTage? [MINimum|MAXimum]
VOLTage:OFFSet {<
offset>|MINimum|MAXimum}
VOLTage:OFFSet? [MINimum|MAXimum]
VOLTage:UNIT {
VPP|VRMS|DBM|DEFault}
VOLTage:UNIT?
OUTPut:LOAD {
50|INFinity|MINimum|MAXimum}
OUTPut:LOAD? [MINimum|MAXimum]
OUTPut:SYNC {OFF|
ON}
OUTPut:SYNC?
*SAV {0|1|2|3} State 0 is the instrument state at power down.
*RCL {0|1|2|3} States 1, 2, and 3 are user-defined instrument states.
MEMory:STATe:DELete {0|1|2|3}
Default parameters are shown in bold.
Chapter 4 Remote Interface Reference
SCPI Command Summary
128
