VOLTage {<amplitude>|MINimum|MAXimum}
Set the output amplitude for the currently active function.
MIN selects
the smallest amplitude allowed for the selected function (50 mVpp into
50 ohms).
MAX selects the largest amplitude allowed (10 Vpp into
50 ohms). The default amplitude is 100 mVpp (into 50 ohms).
[ Stored in volatile memory ]
For arbitrary waveforms, the maximum amplitude will be limited if
the data points do not span the full range of the output
DAC (Digital-
to-Analog Converter). For example, the built-in “
SINC” waveform does
not use the full range of values between
1 and therefore its
maximum amplitude is 6.084 Vpp (into 50 ohms).
You can set the units for output amplitude to Vpp, Vrms, or dBm.
See the VOLT:UNIT command for more information.
For dc volts, the output level is actually controlled by setting the
offset voltage. You can set the dc voltage to any value between
5 Vdc
into 50 ohms or
10 Vdc into an open circuit. See the VOLT:OFFS
command for more information.
Function
Sine
Square
Triangle
Ramp
Noise
Built-In Arbs
1
Sine
Square
Triangle
Ramp
Noise
Built-In Arbs
1
Output
Termination
50
W
50
W
50
W
50
W
50
W
50
W
Open Circuit
Open Circuit
Open Circuit
Open Circuit
Open Circuit
Open Circuit
Minimum
Amplitude
50 mVpp
50 mVpp
50 mVpp
50 mVpp
50 mVpp
50 mVpp
100 mVpp
100 mVpp
100 mVpp
100 mVpp
100 mVpp
100 mVpp
Maximum
Amplitude
10 Vpp
10 Vpp
10 Vpp
10 Vpp
10 Vpp
10 Vpp
20 Vpp
20 Vpp
20 Vpp
20 Vpp
20 Vpp
20 Vpp
1
There are five built-in arbitrary waveforms stored in non-volatile memory:
sinc, negative ramp, exponential rise, exponential fall, and cardiac.
Chapter 4 Remote Interface Reference
Output Configuration Commands
148
