Instrument Shipping Information
30 Agilent 5100 and 5110 ICP-OES Site Preparation Guide
Agilent ICP-OES instrument crate
Particular attention should be made to the clearance of any doors in
the transit route to the laboratory. The required turning and door
clearance may need to take into consideration any lifting device used
for transporting the instrument (for example, fork lift, pallet truck or
trolley).
Figure 5. Maximum clearance required for transportation in the shipping crate
After the in-house transit route requirements have been met, check the checklist box:
Entrance to the lab is at least 1050 mm (41.3 in) wide for packaged instrument, or
800 mm (31.5 in) wide for unpackaged instrument.
Minimum door dimension
1050 mm (41.3 in)
Minimum turning
dimension 1372 mm
(54 in)
