Laboratory Facilities
40 Agilent 5100 and 5110 ICP-OES Site Preparation Guide
Electrical Requirements
Table 6. System electrical specifications
System unit Required supply voltage Nominal rating
Spectrometer 200–240 VAC Single Phase
50 Hz–60 Hz
2.9 kVA
Water chiller (typical) 220–240 VAC, 50 Hz
115 VAC, 60 Hz
1450 VA
1645 VA
SPS 4 Autosampler 100–240 VAC, 47–63 Hz, 1.5 A 24 VDC, 2.5 A
SPS 3 Sample Preparation
System
100–240 VAC, 50–60 Hz ~220 VA
VGA 77 100 VAC
120 VAC
24 VA
220 VAC
Equivalent to 230 VAC
240 VAC
Equivalent to 230 VAC
Frequency 49–61 Hz
SVS 2+ 100–240 VAC, 50–60 Hz 1.8 A
Single phase requirement
The Agilent ICP-OES requires a single phase mains input voltage of
between 200-240 VAC (50-60Hz) and draws a maximum of 15 amps
RMS at 200 to 220 volts and 13 amps at 230-240 volts (2.9 kVA) with
a power factor of approximately 0.99. (Can be a cross phase
connection to achieve specified supply voltage).
Power plugs and cords
The Agilent ICP-OES is supplied with a power cord set appropriate
for the country from which the order originates. For example, if an
order originates from an Agilent Technologies sales office in
Germany, the power cord and plug supplied will be compatible with
the standard voltage and outlet configuration in Germany. See
Appendix A for illustrations of the power cords available.
