6-5
Replaceable Parts
8648A Replaceable Parts
Table 6-1. 8648A Replaceable Parts
Item Part Number Qty. Description
A1 1 FRONT FRAME ASSY (NOT AVAILABLE FOR REPLACEMENT)
A1A1 0960-0856 1 RPG
A1A2 0960-0856 1 RPG
A1A3 08648-60178 1 FLEX CIRCUIT
A1A4 2090-0362 1 DISPLAY VFD 2x40 (Serial prefixes ≥ 3836A/3836U)
2090-0312 1 DISPLAY LCD 2x40 (Serial prefixes < 3836A/3836U)
A1J1 1250-1811 1 RF OUTPUT TYPE-N CONNECTOR
A1MP1 08648-60188 1 FRONT FRAME KIT, 8648A/1E2 (Serial prefixes ≥ 3836A/3836U)
08648-60187 1 FRONT FRAME KIT, 8648A/1EP (Serial prefixes ≥ 3836A/3836U)
08648-60015 1 FRONT FRAME KIT, 8648A Options 1E2/1EP (Serial prefixes
< 3836A/3836U)
A1MP2 08647-40006 1 KEYPAD
A1MP3 08647-00004 1 DISPLAY MOUNT
A1MP4 08647-00019 1 COVER DISPLAY
A1MP5 01650-47401 1 KNOB-CURSOR
A1MP6 01650-47401 1 KNOB-CURSOR
08648-80001 1 NAME PLACE 8648A
A2 0950-2293 1 POWER SUPPLY
A3 08648-60614 1 MOTHERBOARD ASSY (Serial prefixes ≥ 3836A/3836U)
08648-60314 1 MOTHERBOARD ASSY (Serial prefixes < 3836A/3836U)
08648-69614 1 EXCHANGE MOTHERBOARD KIT (Serial prefixes ≥ 3836A/3836U)
08648-69314 1 EXCHANGE MOTHERBOARD KIT (Serial prefixes < 3836A/3836U)
A3A1 08648-60146 1 MEMORY BOARD (FIRMWARE KIT)
A3A1 08648-60165 1 MEMORY BOARD OPTION 1EP (FIRMWARE KIT)
A3BT1 1420-0338 1 BATTERY 3.0V 1.2AH
A3J1 1252-2161 1 CONNECTOR RECT24F
A3J2 1252-1487 1 CONNECTOR RECT 9 F RA
A3J18 1250-1842 1 10 MHZ INPUT BNC
A3J19 1250-1842 1 10 MHZ OUTPUT BNC
A3R6 2100-4507 1 CONTRAST POTENTIOMETER (Serial prefixes < 3836A/3836U)
A3S1 3101-2264 1 TIMEBASE ADJ SWITCH
A4 08647-61045 1 STANDARD REFERENCE ASSEMBLY
