Replaceable Parts
8648A Replaceable Parts
08648-69030 1 EXCHANGE PAGER ENCODER ASSEMBLY (OPTION 1EP)
B1 3160-0866 1 FAN TBAX
F1 2110-0780 1 FUSE 3 A 250 V (NOT SHOWN)
MP1 08647-61025 1 ASSEMBLY CHASSIS KIT (For serial prefixes < 3836A/3836U, also
order 08647-61030)
MP2 08647-00026 1 COVER CARDBOX
MP3 08647-00030 1 COVER-MOTHERBOARD
MP4 08647-00031 1 COVER-RF
MP5 08647-00020 1 MOUNT-POWER SUPPLY
MP6 08648-00012 1 CLAMP (MEMORY BOARD BRACKET)
MP7 (NOT ASSIGNED)
MP8 08647-00028 1 COVER-INSTRUMENT
MP9 5041-3621 1 LINE SWITCH KEY CAP
MP10 5041-8801 4 FOOT FULL MOD
MP11 0515-2086 4 SCREW M4 x .07 7MM-LG 90- DEG-FLH-HD
MP12 0515-0372 22 SCREW MACH. M3 x 0.5 8MM-LG
MP13 0515-0380 35 SCREW MACH.M4 x 0.7 10MM-LG
MP14 0515-2243 4 SCREW MACH. M4.0 12SEMPAN TX
MP15 08647-40003 2 REAR FOOT HANDLE
MP16 (NOT ASSIGNED)
MP17 (NOT ASSIGNED)
MP18 0361-1341 4 RIVET NYL 3.9DIA (HOLDS B1 TO MP1)
MP19 2950-0054 2 NUT HEX 1/2 - 28
MP20 08648-00023 1 MOUNTING BRACKET FOR A30 (OPTION 1EP)
S1 3101-2216 1 LINE SWITCH
0515-1940 2 SCREW MACH 2.5 6PCHPANTX (P/O S1)
W1 08647-61007 1 MODULATION CABLE
W2 08647-61011 1 DISPLAY CABLE
W3 08647-21022 1 RF OUTPUT CABLE (ATTENUATOR TO RF OUTPUT)
W4 08647-61005 1 POWER SUPPLY CABLE
W5 (NOT ASSIGNED)
Table 6-1. 8648A Replaceable Parts
Item Part Number Qty. Description
