Agilent Technologies E3631A User Manual

Chapter 4 Remote Interface Reference
SCPI Conformance Information
110
SCPI Conformance Information
The Agilent E3631A Power Supply conforms to the 1995.0 version of the SCPI
standard. Many of the commands required by the standard are accepted by the power
supply but are not described in this manual for simplicity or clarity. Most of these
non-documented commands duplicate the functionality of a command already
described in this manual.
SCPI Confirmed Commands
The following table lists the SCPI-confirmed commands that are used by the power
supply.
SCPI Confirmed Commands
DISPlay
[:WINDow][:STATe] {OFF|ON}
[:WINDow][:STATe]?
[:WINDow]:TEXT[:DATA] <quoted string>
[:WINDow]:TEXT[:DATA]?
[:WINDow]:TEXT:CLEar
INSTrument
[:SELect] {P6V|P25V|N25V}
[:SELect]?
:NSELect :{1|2|3}
:NSELect?
COUPle[:TRIGger] {ALL|NONE| <list>
COUPle[:TRIGger]?
MEASure
:CURRent[:DC]?
[:VOLTage][:DC]?
OUTPUT
[:STATe] {OFF/ON}
[:STATE]?
[SOURce]
:CURRent[:LEVel][:IMMediate][:AMPLitude] {<current>|MIN|MAX}
:CURRent[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX]
:CURRent[:LEVel]:TRIGgered[AMPLitude] {<current>|MIN|MAX}
:CURRent[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX]
:VOLTage[:LEVel][:IMMediate][:AMPLitude] {<voltage>|MIN|MAX}
:VOLTage[:LEVel][IMMediate][:AMPLitude]?[MIN:MAX]
:VOLTage[:LEVel]:TRIGgered[:AMPLitude] {<voltage>|MIN|MAX}
:VOLTage[:LEVel]:TRIGgered[:AMPLitude]?[MIN|MAX]
