Chapter 3 Front-Panel Operation
Constant Voltage Operation
38
Constant Voltage Operation
To set up the power supply for constant voltage (CV) operation, proceed as follows.
1 Connect a load to the desired output terminals.
With power-off, connect a load to the desired output terminals.
2 Turn on the power supply.
The power supply will go into the power-on / reset state; all outputs are disabled (the
OFF annunciator turns on); the display is selected for the +6V supply (the +6V
annunciator turns on); and the knob is selected for voltage control.
3 Enable the outputs.
The OFF annunciator turns off and the +6V and CV annunciators are lit. The blinking
digit can be adjusted by turning the knob. Notice that the display is in the meter mode.
“Meter mode” means that the display shows the actual output voltage and current.
To set up the power supply for +25V supply or -25V supply operation, you should
press the or key to select the display and adjust for +25V supply or
-25V supply before proceeding to the next step.
4 Set the display for the limit mode.
Notice that the Lmt annunciator blinks, indicating that the display is in the limit mode.
When the display is in the limit mode, you can see the voltage and current limit values
of the selected supply.
In constant voltage mode, the voltage values between the meter mode and limit
mode are the same, but the current values are not. Further if the display is in the
meter mode, you cannot see the change of current limit value when adjusting the
knob. We recommend that you should set the display to “limit” mode to see the
change of current limit value in the constant voltage mode whenever adjusting the
knob.
Power
Display
Limit
Output
On/Off
To Next Page
