Chapter 4 Remote Interface Reference
Simplified Programming Overview
74
Programming Ranges and Output Identifiers
Output setting commands require a parameter for programming ranges and an output
name or an output number as the identifier of each output and most queries will return
a parameter. The programming range for a parameter varies according to the selected
output of the power supply. The following table lists the programming ranges, output
names, and output numbers for each output.
Refer to this table to identify parameters when programming the power supply.
Table 4-1. Agilent E3631A Programming Ranges and Output Identifiers
Output
+6V output +25V output -25V output
Voltage Programming
Range
0 to 6.18 V 0 to +25.75 V 0 to -25.75 V
MAX value 6.18 V 25.75 V -25.75 V
MIN value 0 V 0 V 0 V
*RST value
(DEFault value)
0 V 0 V 0 V
Current Programming
Range
0 to 5.15 A 0 to 1.03 A 0 to 1.03 A
MAX value 5.15 A 1.03 A 1.03 A
MIN value 0 A 0 A 0 A
*RST value
(DEFault value)
5 A 1 A 1 A
Output identifier P6V P25V N25V
Output number 12 3
