Chapter 8 Specifications
Supplemental Characteristics
161
8
Supplemental Characteristics
Output Programming Range (maximum programmable values)
+6V Output
+25V Output -25V Output
Voltage 0 to 6.18 V 0 to 25.75 V 0 to -25.75 V
Current 0 to 5.15 A 0 to 1.03 A 0 to 1.03 A
Temperature Coefficient
, ±(% of output + offset)
Maximum change in output/readback per °C after a 30-minute warm-up
+6V Output
+25V Output -25V Output
Voltage 0.01% + 2 mV 0.01% + 3 mV 0.01% + 3 mV
Current 0.02% + 3 mA 0.02% + 0.5 mA 0.02% + 0.5 mA
Stability
, ±(% of output + offset)
Following a 30-minute warm-up, with the output in the ON state according to the
operating mode (CC with load or CV), and with a change in the output over 8 hours
under constant load, line, and ambient temperature
+6V Output
+25V Output -25V Output
Voltage 0.03% + 1 mV 0.02% + 2 mV 0.02% + 2 mV
Current 0.1% + 3 mA 0.05% + 1 mA 0.05% + 1 mA
Voltage Programming Speed
Maximum time required for output voltage to settle within 1% of its total excursion
(for resistive load). Excludes command processing time.
+6V Output
+25V Output -25V Output
Full load Up 11 msec 50 msec 50 msec
Full load Down 13 msec 45 msec 45 msec
No load Up 10 msec 20 msec 20 msec
No load Down 200 msec 400 msec 400 msec
Isolation
The 0-6V supply is isolated from the ±25V supply up to ±240 Vdc. Maximum
isolation voltage from any terminal to chassis ground ±240 Vdc.
AC Input Ratings
(selectable via rear panel selector)
std 115 Vac ± 10%, 47 to 63 Hz, 350 VA Max
opt 0E3 230 Vac ± 10%, 47 to 63 Hz, 350 VA Max
opt 0E9 100 Vac ± 10%, 47 to 63 Hz, 350 VA Max
