Chapter 3 Front-Panel Operation
Remote Interface Configuration
52
To Set the GPIB Address
To configure the power supply for the GPIB interface, proceed as follows:
1 Turn on the remote configuration mode.
You will see the above message on the front-panel display if the power supply has not
been changed from the default setting. If “RS-232” appears, choose “HPIB / 488” by
turning the knob to the right.
2 Select the GPIB address.
The address is set to “05” when the power supply is shipped from the factory. Notice
that a different GPIB address may appear if the power supply has been changed from
the default setting.
3 Turn the knob to change the GPIB address.
The displayed address is changed when turning the knob to the right or left.
4 Save the change and turn off the I/O configuration mode.
The address is stored in non-volatile memory, and does not change when power has
been off or after a remote interface reset. The power supply displays a message to
show that the change is now in effect. If the GPIB address is not changed, “NO
CHANGE” will be displayed for one second.
Note To cancel the I/O configuration mode without any changes during the GPIB address
selection, press the “I/O Config” key until the “NO CHANGE” message is displayed.
HPIB / 488
ADDR 05
CHANGE SAVED
I/O Config
I/O Config
I/O Config
