Menu Reference
Front Panel Menu Reference "System/Inputs" Menu
Agilent E4419B User’s Guide 3-25
■
Press this softkey to access a menu and screen which allows
you to select and edit frequency dependent offset tables. Use
the and hardkeys to scroll through the displayed
frequency dependent offset tables.
◆
Press this softkey to access a menu and screen which allows
you to modify, add and remove frequency, calibration factors
and offsets from the currently selected table and modify the
table name. Use the , , and hardkeys to
move between the name, frequency, calibration factors and
offsets. Press , or as follows:
❖
Press this softkey to modify the highlighted parameter,
which is either a frequency, calibration factor, offset or
table name. A pop up window displays the parameter. Use
the , , and hardkeys to change the
parameter value. To confirm your choice press .
❖
Press this softkey to insert a new table entry. You are
prompted to enter the frequency and calibration factor or
offset. The entry is inserted in ascending frequency order.
❖
Press this softkey to delete a table entry. If you delete the
frequency the corresponding calibration factor or offset is
also removed and vice versa.
❖
Press this softkey to return to the measurement screen.
The softkeys from the first level of the “System/Inputs”
menu are displayed.
◆
Press this softkey to enable and disable the highlighted table
for channel A. “A” or “B” is displayed beside each table to
indicate it’s current state and use.
◆
Press this softkey to enable and disable the highlighted table
for channel B. “A” or “B” is displayed beside each table to
indicate it’s current state and use.
Freq Dep Offset
Edit Table
Change Insert Delete
Change
Enter
Insert
Delete
A Table Off On
B Table Off On
HP4402.book Page 25 Thursday, November 30, 2000 1:39 PM
