Power Meter Operation
Making Measurements with the Agilent 8480 Series Power Sensors
2-18 Agilent E4419B User’s Guide
Making Measurements with the Agilent 8480 Series
Power Sensors
This section applies to all Agilent 8480 series power sensors. It does not
apply to the Agilent E-series power sensors.
For the Agilent 8480 series power sensors there are two methods of
providing correction data to the power meter:
A inputting the individual calibration factor for a frequency prior to
making the measurement, or
B using sensor calibration tables.
This section describes how to make measurements without using sensor
calibration tables, that is, inputting the individual calibration factor for a
frequency prior to making the measurement. This method is
advantageous if you are only measuring at one frequency, as entering all
the calibration data in this instance is not required.
To make measurements without sensor calibration tables perform the
following steps:
1. Zero and calibrate the power meter. Before carrying out the
calibration you must set the reference calibration factor of the
power sensor.
2. Set the calibration factor value for the frequency of the signal you
want to measure.
3. Take a reading.
Procedure
The following procedure details how to make a measurement on
channel A. To make a measurement on channel B use the same procedure
using the equivalent channel B softkeys.
1. Ensure that no power is applied to the power sensor.
2. Press .
3. Press . During zeroing, which takes approximately 10
seconds, the wait symbol is displayed.
4. Press .
5. Connect the power sensor to the POWER REF output.
Zero
Cal
Cal
